CHORD - PRIMA
CHORD - PRIMA

CHORD - PRIMA

Mã sản phẩm: 1422
129,840,000₫

Thiết kế Chord mang đặc trưng của John Franks, cựu kỹ sư hàng không đồng thời là giám đốc hãng. Bộ cấp nguồn chuyển mạch bằng xung siêu cao tần lắp song song giúp cho amply của Chord đạt độ động và độ tuyến tính cực cao ở mọi mức âm lượng. Công nghệ giải mã FPGA thiết kế bởi Rob Watts đã khẳng định đẳng cấp của thương hiệu Chord DAC.
Mô tả sản phẩm

CHORD - PRIMA

Được thiết kế trên cơ sở của dòng sản phẩm Choral, Prima là một preamp thỏa mãn được tất cả những kỳ vọng của Chord về một thiết bị có chất lượng trình diễn hoàn hảo ẩn chứa bên trong lớp vỏ đẹp như một món đồ trang sức thời thượng.

Prima-Top-900x675

Prima sở hữu hệ thống mạch dual-bus bản quyền của Chord, giúp những tín đồ băng cối dễ dàng ghi những track từ một nguồn input trong khi vẫn thưởng thức nhạc từ một nguồn input khác. Máy cũng được trang bị bộ cấp nguồn UHF danh tiếng của Chord.

Mạch âm thanh của Prima được thiết kế kiểu cân bằng tuyệt đối, máy có 5 ngõ vào RCA có thể điều chỉnh gain độc lập, một ngõ vào cân bằng XLR và một ngõ ra trở kháng thấp cho ampli công suất.

Prima-Rear-900x675

CHORD - PRIMA

Our Prima preamp forms part of the stylish and compact Choral range and has been designed to complement our Mezzo power amps. Despite its compact dimensions and space-saving footprint, the Prima is every bit a pedigree Chord amplifier.

Precision-machined from solid aircraft-grade aluminium billet, the Prima offers both remote control and front panel operation. Prima’s fascia offers volume and balance controls while its push-button controls atop the unit, offer input selection and tape line selection, the latter enabling its tape outputs to be selected for recording from source components.  Further design features include a top panel display, offering input choice and volume information, plus a clever porthole which enables the internal circuit board to be seen.

The Prima also benefits from our legendary proprietary Ultra-High-Frequency power supply, which is common to all Chord amplifiers. Prima offers fully balanced circuitry throughout and useful flexibility with five inputs, four unbalanced RCA and one balanced XLR, plus a balanced XLR output and a tape output. For added versatility, Prima’s audio circuit offers six independent input gain adjustments for the five inputs and low impedance outputs.

 Prima-User-Manual.pdf

 Prima-Specifications.pdf

 Prima-Quickstart.pdf

THÔNG SỐ KỸ THUẬT

FREQUENCY RANGE: 2.5Hz – 200kHz (-3dB)
OUTPUT IMPEDANCE 100Ω (Short Circuit Protected)
OPERATING VOLTAGE 50v – 260v AC (50Hz – 60Hz) Auto Switching
DIMENSIONS 335mm (w) x 170mm (d) x 65mm (h)
WEIGHT 8kG
