CHORD - ULTIMA
CHORD - ULTIMA

CHORD - ULTIMA

Mã sản phẩm: 1421
1,072,500,000₫

Thiết kế Chord mang đặc trưng của John Franks, cựu kỹ sư hàng không đồng thời là giám đốc hãng. Bộ cấp nguồn chuyển mạch bằng xung siêu cao tần lắp song song giúp cho amply của Chord đạt độ động và độ tuyến tính cực cao ở mọi mức âm lượng. Công nghệ giải mã FPGA thiết kế bởi Rob Watts đã khẳng định đẳng cấp của thương hiệu Chord DAC.
Mô tả sản phẩm

CHORD - ULTIMA

Amply công suất mono-block ULTIMA được lên ý tưởng dành cho những hệ thống audio high-end cầu kỳ và tinh xảo nhất, những hệ thống đòi hỏi bộ khuếch đại khả năng chế ngự được những bộ loa lớn. ULTIMA cho ra mức công suất vô đối và khả năng tải mọi cặp loa.

Ultima-Top-900x675

ULTIMA là mẫu amply hoàn thiện nhất trong lịch sử 30 năm của công nghệ amply bản sắc Chord Electronics. Nó sở hữu thiết kế mạch hoàn toàn mới, lần đầu tiên được áp dụng từ trước tới nay. Công nghệ khuếch đại mới mạch với tiếp thuận kép – sửa lỗi trước (dual-feedforward error-correction) được phát minh bởi tiến sỹ Malcom J Hawksford (giáo sư đại học Essex) và được tinh chỉnh bởi Bob Cordell của Bell Labs.

ULTIMA chứa đựng công nghệ amply thế hệ mới của Chord, một thiết kế sở hữu nền tảng feedforward error-correction của Cordell cộng với thiết kế bộ cấp nguồn siêu cao tần danh tiếng của John Frank.

ULTIMA trang bị tới 64 transistor công suất MOSFET được Chord đặt chế tạo riêng. Mạch đẩy với độ méo siêu thấp, công nghệ khuếch đại điện áp cao làm việc ở tốc độ lớn: 300 volt/ msec với kỹ thuật tiếp thuận và bù hồi tiếp âm.

Ultima-Side-900x675
Ultima-Rear-900x675

PHỤ KIỆN VÀ CHỌN LỰA KHÁC

Bộ chân mặt nhôm thô - Raw aluminium Integra leg option.

Bộ chân nhôm  mạ anode màu đen - Black anodised aluminium Integra leg option.

Bộ chân nhôm mạ ni-ken - Nickel plated aluminium Integra leg option.

Ốp hông bằng acrylic đen - Thay thế chân nhôm - Gloss black acrylic side block option – replaces aluminium Integra legs.

 ULTIMA-User-Manual.pdf

 ULTIMA-Quickstart.pdf

CHORD - ULTIMA

The ULTIMA mono power amplifiers have been conceived for the very finest high-end audio systems, those which by their very nature, tend to have the most demanding and most difficult-to-drive large loudspeakers. They deliver unsurpassed power delivery and are capable of effortlessly driving any speaker.

ULTIMA is the company’s most accomplished amplifier in its 30-year history and one that draws on Chord Electronics’ three decades of proprietary-technology amplifier manufacturing. It features an all-new circuit topology, the first completely new design since those early days. The new dual-feed forward error-correction amplifier technology is a progression of Dr Malcolm J Hawksford’s (emeritus professor at Essex University) technical paper, refined by Bob Cordell of Bell Labs.

ULTIMA contains Chord Electronics’ next-generation amplifier tech, a design which features Cordell’s advanced dual-feedforward error-correction topology, plus John Franks’ own advanced concepts in ultra-high-frequency power supplies.

The ULTIMA mono amplifier unit has an incredible 64 proprietary MOSFET power devices that demand the most advanced and refined drive circuitry, suitably devoid of sound-degrading components. The drive circuitry features an ultra-low-distortion, high-voltage amplifier operating at very high speed: 300 volts-per-microsecond technologies with advanced feed-forward and feedback compensation techniques.

ULTIMA is incredibly powerful and offers 780 watts into 8 ohms, 1,400 watts into 4 ohms and 2,500 watts into 2 ohms. ULTIMA’s peak output current exceeds 500 amps, an extremely high current differentiated by the speed at which the dynamic peaks can be delivered, bringing astonishing dynamics, fidelity and unrivalled musicality.

ULTIMA is truly an unprecedented amplifier design with exceptional performance and is one of the most advanced hi-fi amplifiers in the world.

THÔNG SỐ KỸ THUẬT

OUTPUT POWER

780w RMS per channel @ 0.05% distortion into 8Ω

1405w RMS per channel into 4Ω

FREQUENCY RESPONSE -1dB @ 0.2Hz to 46kHz and -3dB 0.1Hz to 200kHz
SIGNAL TO NOISE RATIO Better than -90dB
CHANNEL SEPARATION Better than 90dB
INPUT IMPEDANCE 100kΩ Unbalanced/Balanced
OUTPUT IMPEDANCE 0.04Ω
GAIN 30dB
DIMENSIONS WITH INCLUDED INTEGRA LEGS 30.5cm (H) x 48cm (W) x 67cm (D)
DIMENSIONS WITH OPTIONAL SIDE BLOCKS 28.5cm (H) x 42cm (W) x 67cm (D)
